HFZ
Factory-supplied line · CJWR
A guided pneumatic cylinder for stable parallel travel in fixtures and handling mechanisms.
Product overview
The HFZ family supports guided linear motion for fixture building, transfer mechanisms and machine automation where stable travel and practical mounting are needed.
| Guide design | Guide-rod cylinder |
|---|---|
| Series size range | Ø6–Ø40 |
| Motion | Guided linear pneumatic travel |
| Mounting | Select according to application drawing |
We confirm mounting pattern, port thread, stroke and sensor groove before quoting.
Check compatibilityEngineering details
CAD download center
0 / 2 formats ready to download for this model · Browse the CAD library
STEP 3D CAD Model
3D CAD file available on request
2D Dimension Drawing
Dimension drawing available on request
Need a format that is not listed? Include the required file format in your RFQ.
