4V210-08
A 5-port directional solenoid valve with 1/8 in ports for double-acting cylinder control.
Product overview
The 4V210-08 is a compact five-port directional control valve with responsive spool action, a manual override and manifold mounting capability. It is suitable for general industrial automation and pneumatic control circuits.
| Valve function | 5/2-way |
|---|---|
| Port size | 1/8 in |
| Voltage | DC24V / AC220V |
| Operating pressure | 0.15–0.8 MPa |
| Cv value | 0.78 |
| Max. frequency | 5 cycles/s |
| Temperature | -5 to +50 °C |
We confirm mounting pattern, port thread, stroke and sensor groove before quoting.
Check compatibilityEngineering details
CAD download center
0 / 2 formats ready to download for this model · Browse the CAD library
STEP 3D CAD Model
Universal 3D CAD format
2D Dimension Drawing
Mounting drawing
Need a format that is not listed? Include the required file format in your RFQ.
